THE BOX FITS.
DOES THE
MOVEMENT?

A machine's footprint, space needed during use and stored size are different measurements. Compare them separately.

  1. 01Measure clear floor
  2. 02Check use space
  3. 03Resolve headroom

Start with the room

Three sourced examples.
No generic clearance allowance.

Every model is checked separately in both floor orientations. This is dimension comparison, not object packing, installation approval or safe exercise clearance.

Open the ceiling and footprint calculator

All four measurements use the selected unit. Blank optional fields stay unknown. Measure at the intended location, including low beams or lights.

The source record / November 3, 2026

Footprint is the first check.

As an Amazon Associate, we earn from qualifying purchases. Only the AB-3100 listing was verified to the named model here. Retail marketing about folding or decline does not override REP's specifications. No current price or availability is claimed.

Inches; dimensions describe the named configuration
ModelBody footprintMaker use rectangleHeight and unresolved checksSource
REP AB-310023 wide × 50.5 deepNot verified16.75 inches is the flat bench height. Raised-back height and exercise clearance are not established here. REP says this model is not designed for vertical storage; nominal dimensions have 3% tolerance.Manufacturer specifications
View REP AB-3100 on Amazon
Concept2 RowErg, standard legs24 wide × 96 deep48 wide × 108 deepMaker recommended use space is 9 by 4 feet. Separated storage is 25 by 33 by 54 inches for standard legs. Storage height is not an operating ceiling requirement. Exact Amazon leg variant was not established.Manufacturer specifications
BowFlex Max Trainer M626 wide × 46 deepNot verifiedMaker minimum ceiling is user height plus 20.5 inches. This rule is specific to M6. A verified operating floor envelope is not supplied in this comparison.Manufacturer specifications

Three checks, worked through.

01 / FLOOR

16 square feet is not 36.

RowErg's body is 96 × 24 ÷ 144 = 16 sq ft. Its recommended use rectangle is 108 × 48 ÷ 144 = 36 sq ft. A 96-by-24-inch space contains the body but fails the use-space comparison.

02 / CEILING

72 + 20.5 = 92.5 inches.

For a 72-inch user, M6's stated minimum ceiling is 92.5 inches. A 90-inch ceiling misses that condition by 2.5 inches. Meeting it does not resolve the unknown operating floor envelope.

03 / BENCH

Flat height is not headroom.

AB-3100's 16.75-inch flat height cannot clear its raised back, the user's body or an overhead movement. The checker leaves those requirements unresolved.

Storage is another measurement

Keep the dumbbell and cradle separate.

Two manufacturer dimension records, checked November 3, 2026
ConfigurationBodyCradle or storageWhat the comparison means
REP QuickDraw, 60 lb configuration18.5 inches long; 7.3-inch plate diameterOne cradle: 20.6 by 8.45 inches; 7.9 inches high with dumbbellThe 30/40/50 lb bodies are 12.2/14.3/16.4 inches long. A pair of cradles side by side is 16.9 inches wide before a gap; this is arithmetic, not recommended operating spacing. Maker source
PowerBlock Pro 5013 by 7 by 7.25 inches per dumbbellSeparate stand or operating envelope not verified5 to 50 lb, non-expandable. The published body is 5.5 inches shorter than the QuickDraw 60 lb body, but these systems have different maximum loads. Maker source

These figures do not rate comfort, durability or safe training loads. Exact Amazon capacity variants were not established, so this table makes no direct variant recommendation. For the separate fixed-weight option, read the existing ten-pound dumbbell review.

Legacy BowFlex recall: the maker includes all genuine U.S.-market legacy 552 and 1090 dumbbells, including serials outside the initial notice. They are excluded from this comparison. New Results Series products have separate identities; the existing Results Series review explains the distinction.
